Best Practices for USB Mirror Commands

« Go Back

Information


Issue / QuestionWhat to do if USB mirror commands are not being executed properly?
Applicable ToPrinters with USB host port
Resolution / Answer
If the USB mirror commands are not being executed, try one of the following suggestions.
  • Add the carriage return and line feed characters to the command.
    • Command:
      ! U1 setvar ""ezpl.print_width" "812"<CR><LF>
  • Add the printer reset SGD to the commands file.
    • Command:
      ! U1 setvar ""ezpl.print_width" "812"
      ! U1 setvar "device.reset" ""
  • Delete the E:USBTIMESTAMP.DAT file from the printer's memory before running USB mirror again
    • Command:
      ! U1 do "file.delete" "E:USBTIMESTAMP.DAT"

NOTE The printer will restart automatically when USB mirror is executed successfully.
